In industrial manufacturing, the most minuscule ingredient can have a maximum impact. Particularly so when it comes to thickening agents, compounds that change the viscosity of a product without changing other product properties.
The most reliable and versatile of these agents is Hydroxypropyl Methylcellulose (HPMC). In fact, due to its unique properties, versatility and outstanding performance across many different industries, HPMC is playing a more and more crucial role as a thickening agent in industrial applications.
Table of Contents
Let’s take a closer look at HPMC: what it is, how it works, and why there’s an industrial need—but not just in construction, pharmaceutical, paint or food industries—to get the right consistency.
What is HPMC?
Hydroxypropyl Methylcellulose (HPMC) is a cellulose polymer that has been chemically modified from either wood pulp or cotton plant material. It is non-ionic, biodegradable, and very versatile.
Moreover, HPMC’s molecular structure allows it to dissolve in both hot and cold water while still forming colloidal solutions, giving it the multifunctional properties of a stabilizer, film former, and most importantly, a thickener.
Due to its multifunctional properties, HPMC is used in a wide range of industrial applications, especially when viscosity, consistency, or stability are a concern.
Since HPMC is non-toxic and safe for consumption, it can be incorporated into food and pharmaceutical products, making it a perfect thickener when strict regulatory measures are in place.
How Does HPMC Work as a Thickening Agent?
The thickening action of HPMC is a result of the hydrating and gelling properties of this polymer. When mixed with water, the polymer chains of HPMC hydrate and swell, trapping water molecules and forming a three-dimensional structure that increases the viscosity of the solution.
Several factors influence the thickening efficiency of HPMC:
Concentration – The greater the concentration of HPMC, the greater the viscosity.
Molecular Weight – Polymers that have a greater molecular weight have a greater capacity for thickening.
Degree of Substitution – The addition of hydroxypropyl and methyl groups influences solubility and viscosity.
Temperature – HPMC demonstrates thermal gelation behavior meaning it can form a gel when heated and return to liquid upon cooling.
These features allow HPMC to be tailored to the viscosity requirements of various industrial formulations.
Industrial Uses of HPMC as a Thickener
1. Construction
In construction, materials must be workable, durable, and uniform. HPMC is used in many industrial settings such as cement, mortar, tile adhesives, and gypsum-based products to impart these properties.
HPMC improves water retention so that the mixture does not dry out too quickly. HPMC also improves open time (length of time a material is considered workable) adhesive bond strength, and workability.
Also, HPMC inhibits the segregation of the components in the initial blend, confirming that each batch is consistent from start to finish. This permits ease of use and consistency and impacts the structural integrity of the finished system.
2. Paints and Coatings
Viscosity is important for the properties in paints such as spread ability, sag resistance, leveling, and other performance characteristics, and HPMC aids in viscosity control to assist paint manufacturers control the flow and spread of paints by using HPMC as a rheology modifier.
Similarly, it aids in pigment suspension and does this with pigments while allowing for even distribution and even prevention of sedimentation and allowing for uniformity of color and texture.
Also, because HPMC is non-ionic, HPMC has no adverse reactivity in paints that may cause a detrimental effect and confirms the paint also maintains stability/quality in-situ.
3. Pharmaceutical Industry
In the pharmaceutical sector, HPMC has many different uses including as a thickening agent in syrups, as a thickening agent in topical gels, and as a thickening agent in eye drops.
It provides a smooth consistency/produce a solute that can easily be disseminated or consumed by the subject.
Additionally, HPMC can be used as a film former when used as a coating agent for tablets, as the film can protect the overall tablet itself from moisture and provide another layer of protection.
HPMC is also commonly used with controlled release formulations. After being ingested, HPMC forms a gel layer that slows the release of the active pharmaceutical ingredient (API). This results in a prolonged delivery of drug over time. For chronic treatments, it is often important for delivery to be consistent.
4. Personal Care and Cosmetics
HPMC is used in personal care items (shampoos, conditioners, lotions, creams, etc.) as a thickener and stabilizer. As a result, it provides a rich smooth texture that gives the user a better experience.
Since HPMC is non-toxic and a hypoallergenic, it can be used for sensitive skin and usually in baby ness products.
Its ability to maintain viscosity over broad temperatures and pH ranges makes it stable in formulations that require longevity.
5. Food Industry
While it may seem surprising, HPMC is also used in food processing as a thickener, emulsifier, and stabilizer. You would find it in salad dressings, sauces, dessert toppings and also low-fat ice creams.
In gluten-free baking, HPMC replaces the gluten and provides the dough with the required elasticity and viscosity of gluten, which improves the texture and volume of the gluten-free baked product. HPMC is also used in vegan-friendly foods as a vegetarian substitute for gelatin and other animal-based thickeners.
6. Cleaning Products
A variety of commercial and household cleaners need to cling well to a surface long enough to dissolve the dirt and grime.
HPMC thickens these formulations by converting them into a more viscous formulation, resulting in greater surface contact over which the product can perform, and therefore greater cleaning efficiency.
In liquid detergent formulations, HPMC thickens the formulations, prevents phase separation, and improves the aesthetic quality of the product.
The Benefits of HPMC in Industrial Applications
There are many benefits of using HPMC as a thickener in industrial applications, which go further than just providing viscosity:
1. Water Retention
HPMC retains large quantities of water, a property that is important in construction materials and personal care products. HPMC provides moisture during the curing of cement products and avoids drying out in skin-care products.
2. Workability
Using HPMC improves the workability of a product, whether in tile adhesives or lotions. It makes it easier for consumers to apply the product, and therefore the end-user experience will be improved and possibly result in higher satisfaction for the product.
3. Thermal Gelation
One of the more unusual properties of HPMC is that it gels during heating and reverts to a liquid upon cooling. This is an important property, particularly in the food and pharmaceutical industry.
4. Stable Over Time
HPMC’s thickening capacity does not change depending on up to very high levels of pH and temperature; it is also some what resistant to microbial decay, providing a long shelf life.
5. Compatibility
Being non-ionic means that HPMC would not crosslink or react with other charged molecules. This renders it compatible with almost all ingredients used in industrial formulations.
6. ‘Green’, Human-safe
HPMC is sourced from renewable characteristics and is biodegradable, making its use safer for human and environmental health; HPMC is also approved by the FDA for use in food- and pharmaceutical-based products in the kitchen and/or our medicine cabinets…
Market Trends and Future
As there is a growing demand for sustainable, functional, and effective ingredients in various industrial applications, HPMC is a natural fit. Its multiple functionality means not needing to incorporate as many additives into a product, thereby decreasing manufacturing costs and increasing productivity.
Globally, HPMC is seeing exponential growth in market share, led by its various uses in construction (particularly in emerging economies), pharmaceuticals, and food products.
The movement towards green and sustainable initiatives is being propelled by the increased usage of biodegradable and plant-based ingredients such as HPMC.
As industries in general continue to place a premium on performance, sustainability, and costs, HPMC will continue to play an ever-more-important role, especially the thickening agent, in industrial applications.
Final Thoughts
In a time where precise performance is vital, what goes into a product is often the deciding factor for success. HPMC is a true player, with excellent thickening ability, high compatibility, and a better fit alongside many environmentally sensitive ingredients across a multitude of industries.
HPMC applications range, in no particular order, from construction and paints, through to pharmaceuticals and personal care, to provide all users; consistency, improved workability, long term stability, and less complexity.
As a thickener for use in industrial applications, HPMC contributes to meeting the performance needs of the current manufacturers but is also a progressive ingredient that allows for innovative products and sustainability in our future offerings.
So whether you are designing a new medical formulation of a state-of-the-art building material, evaluating the inclusion of an HPMC in your formulation could be the defining decision that sets your product distance apart from a functional, usable, successful, or in the case of a product that creates, aspirational engaging and exciting, aspirational product.
