In pharmaceuticals, nothing is more important than precision. From the choice of active ingredients to excipients, everything is important to the safety, efficacy, and stability of the finished product.
One important excipient is Hydroxypropyl Methylcellulose (HPMC); this polymer can be used as a binder, film-coating agent, thickener, and controlled-release matrix.
Table of Contents
However, just as not all lifestyles are the same, not all grades of HPMC are the same. The grade of HPMC you choose can be the difference between getting your formulation right and failing quality testing.
This guide will help you through the selection process for HPMC for pharmaceutical applications, focusing on HPMC E15.
What is HPMC, and What is the Importance of Grade?
HPMC is a semi-synthetic, inert, and water-soluble polymer derived from natural cellulose. HPMC is produced through etherification, which involves replacing hydroxyl groups on cellulose with methoxy and hydroxypropoxy groups.
The chemical treatment will yield different grades of HPMC, and the various grades will have differences in viscosity, solubility, and film-forming properties.
In pharmaceuticals, the grade you select will directly affect:
- Drug release profile
- Film integrity during coating
- Viscosity of solutions or gels
- Suspension stability in liquids
For instance, the viscosity range of HPMC can dictate how quickly the tablet releases its drug content, whether it be in the range of minutes to hours.
Understanding HPMC Grades
HPMC grades are typically classified by viscosity, molecular weight, and degree of substitution (DS).
1. Viscosity Classification
Viscosity is commonly expressed in millipascal-seconds (mPa∙s), and measured as a 2% aqueous solution. Viscosity is the most important factor when choosing an HPMC grade for particular drug applications.
Low Viscosity Grades (LV) – Use where minimal thickening is required, such as low viscosity coatings, or fast dissolving films.
Medium Viscosity Grades (MV) – Considered a good balance between film strength and flow, and typically used to coat many oral solid dose coatings and suspensions.
High Viscosity Grades (HV) – Used in controlled release systems where high gel strength, minimizing the drug release rate, is required.
Example: HPMC E15 is a medium viscosity grade (~15 mPa∙s) that is suitable for film coating applications, due to the proper balance of workability, adhesion, and barrier properties.
2. Molecular Weight and Film Forming Ability
The films formed with higher molecular weight HPMC grades will hopefully be stiffer and stronger, which can be useful for sustained release type tablets. Lower molecular weight HPMC grades will dissolve slowly when soaked, so they will be suitable for essentially immediate release coating.
3. Degree of Substitution (DS)
The DS has an impact on water solubility, gel strength, and compatibility with APIs. The higher the substitution, the better the solubility, which makes the polymer much easier for processing in aqueous systems, which is a massive advantage as the pharmaceutical industry is moving toward solvent-free manufacturing.
HPMC For Pharmaceutical Applications
HPMC is a versatile polymer used in many facets of manufacturing pharmaceuticals and benefits many delivery forms, including:
Tablet Coatings – Increases stability, protects against moisture and oxygen, and improves swallowability. More than likely, HPMC E15 is used because it will provide a smooth coating and a reliable adherence for coating for pharmaceutical and dietary applications.
Controlled-Release matrices – As the HPMC grade increases in viscosity, its ability to slow down water penetration increases, and it helps control the drug release profile.
Suspensions and Syrups – Helps to slow down particle sedimentation to achieve consistent, uniform liquid formulations.
Ophthalmics – provides viscosity to lubricate in eye drop formulations.
How to Choose the Correct HPMC Grade for Your Application?
Choosing the correct HPMC grade for pharmaceutical applications is not just choosing (and pulling) one from a catalogue – it is an experience of matching the properties of polymers with the desired formulation goals.
1. Define Your Application Needs
Film Coating: Use medium viscosity grades such as HPMC E15 primarily, as it provides adequate film strength while not being too thick, which is beneficial during coating operations.
Controlled Release: Use high viscosity grades to achieve the proper gel layer to slow the diffusion of the drug.
Suspensions: Use medium viscosity HPMC to ensure stable dispersion without excessive thickening.
2. Consider Hydrophilicity and Water Retention
In controlled release formulations, water retention would be positively correlated to viscosity and therefore prolonged release. In the case of coating, too high a viscosity grade could worsen the throwing of the spray, and therefore, a medium viscosity, such as E15, provides that balance.
3. API Considerations
The API may interact with some grades of HPMC, which can affect dissolution or stability, so it is important to always conduct the necessary compatibility studies to ensure that the polymer will not affect the potency of the API.
4. Consider Production Environment
The temperature and humidity during production can also affect the performance of HPMC. For example, during production in a high-humidity environment, you may want a higher viscosity grade to counteract the water uptake from the environment.
5. Ensure Regulatory Compliance
Make sure that whatever HPMC grade you are using has adequate pharmacopeia compliance (USP, Ph. Eur., JP). Pharmaceutical grade HPMC must have controls to keep impurities below a certain level, controls for viscosity consistency, and controls for substitution.
Spotlight: HPMC E15 – The Go-To Grade for Film Coating
If there is one grade that achieves a perfect balance for many solid dosage applications, it is HPMC E15.
Why is HPMC E15 so Acceptable in Pharma?
Optimal viscosity: ~15 mPa·s viscosity of HPMC E15 facilitates good sprayability and uniformity during film coating.
Strong film integrity: These films are less likely to crack and peel off during handling and storage.
Moisture barrier: HPMC E15 provides appropriate barrier protection for moisture-sensitive APIs.
Patients have comfort: HPMC E15 provides a smooth, glossy tablet surface, making it easy to swallow.
No shortage of pharmaceutical manufacturers will turn to HPMC E15 for both functionality and aesthetics. HPMC E15 readily incorporates pigments, plasticizers, and other coating agents, which makes it a reliable option for large-scale production.
Quality Aspects to Consider When Sourcing HPMC
Here are some quality checks to take into consideration when sourcing HPMC:
Viscosity: Variations exist from batch to batch; viscosity can affect the life of the coating.
Residual solvents: Consider low residual solvents; it is a matter of safety and compliance with ICH guidance.
Microbial limits: This consideration is paramount when applying for ophthalmic or liquid oral applications.
Conclusion
Choosing the best grade of HPMC to suit certain pharmaceutical applications is a strategic decision for a manufacturer and can have effects on drug shelf-life, patient experience, and production efficiency.
Whether you are creating a moisture protective film coating, a controlled-release matrix, or a stable suspension, the correct grade – such as the ever-reliable HPMC E15 can make all the difference.
By considering your application needs, formulation compatibility, and production conditions, you can ensure that your HPMC choice enhances both product performance and patient outcomes.
In a field where precision is key, making the right excipient choice is just as important as the active ingredient itself.
